Heavy-Duty Hydraulic Offset Farm Disc Harrow – 10 FT, 14 FT, 17 FT Width Options

Heavy-Duty Hydraulic Offset Farm Disc Harrow – 10FT, 14FT & 17FT Models

OVERVIEW

Engineered for large-scale agricultural operations, this Heavy-Duty Hydraulic Offset Disc Harrow is the ultimate tool for primary tillage and high-performance soil preparation. Designed to penetrate deeply into compacted ground, it efficiently breaks up soil, incorporates crop residue, and prepares a clean seedbed. With integrated hydraulic offset control, oil bath bearings for long-term reliability, and US-grade structural steel, this harrow delivers the durability and precision required for the most demanding farming environments.

SYSTEM HIGHLIGHTS

• Hydraulic Offset Control: Allows for easy adjustments from the tractor cab, ensuring clean edge cuts and optimal maneuverability in the field.

• Oil Bath Bearings: Features high-performance bearings sealed in oil for smooth operation, reduced friction, and significantly extended service life compared to standard grease units.

• Aggressive Cutting Action: Outfitted with half-serrated front discs for aggressive soil penetration and smooth rear discs for a level, consistent finish.

• Industrial-Grade Construction: Built with 65mm high-strength steel (ASTM 1066/USA Grade) to withstand high-stress tillage in rocky or heavy clay soils.

• Heavy-Duty Rim System: Equipped with 11-15 6-bolt rims for superior traction and stability while transporting the unit or working in soft field conditions.

SPECIFICATIONS & DIMENSIONS

Feature	10FT Model	14FT Model	17FT Model
Working Width	3048mm (10FT)	4267mm (14FT)	5182mm (17FT)
SKU Number	614526	614527	614528
Tractor Requirement	100–120HP	150–160HP	160–180HP
Net Weight	2177kg (4800lbs)	3243kg (7150lbs)	4604kg (10,150lbs)
Disc Count	28 Discs	40 Discs	48 Discs
Disc Configuration	Half-Serrated / Smooth	Half-Serrated / Smooth	Half-Serrated / Smooth
Steel Grade	65mm ASTM 1066	65mm ASTM 1066	65mm ASTM 1066

IDEAL APPLICATIONS

Primary Tillage & Soil Aeration - Intensive Field Preparation - Stubble & Heavy Residue Incorporation - Breaking Compacted or Virgin Land - Commercial Farming & Acreage Management
