Industrial Refrigerated Air Dryer 2.0 Nm3 Min 70 CFM Compressed Air Moisture Removal System AD2NF01

Industrial refrigerated air dryer designed to remove moisture, oil mist, and condensate from compressed air systems. This unit cools compressed air to a low dew point, separates moisture, and automatically drains condensate to protect downstream tools, equipment, and processes. Ideal for automotive shops, fabrication, CNC, paint prep, and industrial compressed air applications.

Key Features

• Refrigerated compressed air dryer for industrial systems

• Removes moisture, oil mist, and condensate

• Improves air quality and protects downstream equipment

• Automatic condensate separation and drain

• Continuous-duty operation

• Compact industrial metal enclosure

Specifications

• Product Type: Refrigerated compressed air dryer

• Flow Capacity: 2.0 Nm³/min (≈70 CFM)

• Rated Throughput: 2.0 Nm³/min

• Intake Pressure: 0.6–1.0 MPa

• Max Intake Air Temperature: ≤45°C

• Pressure Loss: ≤0.02 MPa

• Outlet Pressure Dew Point: 2–10°C

• Cooling Method: Air cooled

• Refrigerant: R134a

• Cooling Capacity: 2213 W

• Noise Level: <45 dB(A)

• Electrical: 1 Phase, 220V, 60Hz

• Installation: Floor standing, no foundation required

• Inlet / Outlet Size: Rc 1.0

• Operation: Continuous duty

• SKU: AD2NF01

What’s Included

• 1 × Refrigerated air dryer unit

• Automatic drain (installed)

• User documentation

Recommended Compressor Size

• Suitable for compressors up to 15 HP

• Ideal operating range: 10–15 HP compressors Up to 70 CFM air flow

• Can support 20 HP compressors only if actual air demand stays below 70 CFM

Not recommended for systems exceeding 70 CFM continuous flow.
