2200 lb Portable Electric Pallet Jack Forklift Stacker 1300mm Lift ES121000

This 2200 lb Portable Electric Pallet Jack Forklift Stacker is designed for efficient material handling in warehouses, shops, loading areas, and light industrial environments. Built for pedestrian operation, it provides powered lifting and controlled lowering for safe, precise stacking without the cost or footprint of a full-size forklift.

Powered by a DC 12V 45Ah battery, this compact electric stacker delivers smooth lift performance up to 1300 mm (51.2 in), making it ideal for pallet handling, shelving, and short-distance transport. Its narrow wheelbase and maneuverable design allow easy operation in tight spaces.

Key Features

• 2200 lb (1000 kg) load capacity

• Portable electric pallet jack forklift stacker

• Pedestrian walk-behind operation

• DC 12V 45Ah battery powered

• Smooth electric lifting and controlled descent

• Compact design for tight aisles and small warehouses

• Multiple wheel sizes for stability and maneuverability

• Ideal for warehouses, workshops, loading docks, and retail backrooms

Specifications

• Model: ES121000

• Load Capacity: 2200 lb (1000 kg)

• Load Centre Distance: 15.7 in (400 mm)

• Operation Type: Pedestrian

• Battery: DC 12V 45Ah

• Lifting Height: 51.2 in

• Overall Vehicle Height (Mast Lowered): 65.6 in (1666 mm)

• Lifting Speed: 3.2 in/s (82 mm/s)

• Descent Rate: 2.6 in/s (66 mm/s)

• Wheelbase: 27.9 in (708 mm)

• Front Wheelbase: 15.7 in (398 mm)

• Rear Wheelbase: 27.9 in (708 mm)

• Front Wheel Size: Ø2.8 × 2.4 in (Ø70 × 60 mm)

• Universal Wheel Size: Ø3.9 × 2.0 in (Ø100 × 50 mm)

• Intermediate Wheel Size: Ø2.6 × 1.2 in (Ø65 × 30 mm)

• Lifting Motor: 1.6 kW

• Power Supply: 110V / 60Hz USA plug

What’s Included

• Electric pallet jack stacker unit

• Integrated lifting motor

• DC 12V battery

• Built-in wheel assembly
